Colour
|
Matt Magenta with Black/Purple
|
Frame
|
6061 Hydro Formed T6 Aluminium, Multi Butted, SCR, Tapered Headtube, Internal Cable Routing with BBX, Chainstay Post Mount Dropouts and Get A Grip Seat Clamp System
|
Fork
|
RockShox 30 Silver 27.5", 120mm Travel, Solo Air, Adjustable Rebound, Alloy Steerer, Turn Key Lockout
|
Rear Shock
|
N/A
|
Headset
|
FSA No. 57B Orbit ZS, Caged Lower Bearing 1.5", 1 1.8" Caged Upper Bearings
|
Rear Hub
|
Alloy, Cup & Cone, Double Seal, 32 Hole
|
Front Hub
|
Alloy, Cup & Cone, Double Seal, 32 Hole
|
Spokes
|
WTB 2.0mm, Black Stainless with Brass Nipples
|
Rims
|
Whyte Trail-21, Sleeve Joint, Offset Rims, 32 Hole
|
Tyre
|
Maxxis Ardent Wire 27.5" x 2.25" Front, Maxxis Crossmark II Wire 27.5" x 2.25" Rear
|
Shift Levers
|
Shimano Deore SL-M6000, 10 Speed
|
Front Mech
|
N/A
|
Rear Mech
|
Shimano Deore RD-M6000, Shadow Plus
|
Cassette
|
Sunrace CSMS3, 11-42, 10 Speed
|
Chain
|
Shimano HG-54, 10 Speed
|
Crankset
|
FSA Alpha Drive 1X, Forged Cranks, Narrow Wide 30T Chainring
|
Bottom Bracket
|
FSA Square Taper, 73mm
|
Seatpost
|
Whyte 20mm Offset, 30.9mm x 350mm, 6061 Alloy, 2 Bolt Clamp, Adjuster
|
Saddle
|
Whyte Custom, Triple Panel Design
|
Handlebar
|
Whyte Riser Bar 15mm Rise, 31.8mm, 740mm Wide
|
Stem
|
Whyte Custom, 35mm XS & S, 45mm M
|
Grips
|
Whyte Lock-on V Grip
|
Front Brakes
|
Tektro Auriga, 160mm Rotor
|
Rear Brakes
|
Tektro Auriga, 160mm Rotor, Internal Routing
|
Brake Levers
|
Tektro Auriga
|
Pedals
|
Fibre Reinforced Composite Platform
|
Weight
|
13Kg
|
|
|
