Brand:Mondraker
Code:010.23202
Frame
Factor 26 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 120mm travel, one piece bolt-on upper link, QR 9mm rear axle, 73mm BSA bottom bracket, HHG internal cable routing, dedicated 1x drivetrain design
Sizes
One size: 350mm
Rear shock
X-Fusion 02PRO R, 210x55mm. Settings: low-speed rebound, air preload. 45x8mm top and bottom bushings
Shock settings
A-Tune light compression
Fork
X-Fusion Velvet RL 26, 120mm, air spring, tapered steerer tube, 9x100mm axle, 32mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload
Headset
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Stem
Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
Handlebar
MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips
Onoff Twin, 1lock-on
Seatpost
Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm
Saddle
SDG Fly JR
Front brake
Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear brake
Brake lever
Sram Level, tooled reach adjust, lever pivot bushings
Rims
MDK-XP1 26 TLR, 25mm internal width, tubeless ready, 32 spokes
Spokes
CN round stainless steel
Front hub
Formula DC20LW, 9x100mm, cup & cone ball bearings, IS 6 bolts
Rear hub
Formula DC22LW 9x135mm, cup & cone ball bearings, IS 6 bolts
Front tire
Kenda Booster 26x2.4 single compound 30TPI, wire bead
Rear tire
Crankset
Sram SX Eagle, DUB axle, Direct mount chain ring, 155mm
Rings
30T, steel, X-Sync
Bottom bracket
Sram DUB BSA, sealed bearings, 73mm
Chain
Sram SX Eagle, 12s, Powerlock
Rear derrailleur
Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
Shift levers
Sram Trigger SX Eagle, 12s, X-Actuation 1:1
Casette
Sram XG-1230, 11-50T, 12s
Derailleur hanger
Mondraker M073
Weight
13,6 kg
